Condensate pot :
The main purpose of condensate pot is to catch and hold condensate and foreign material.This prevents damage to the metering system and/or manifold.The condensate may be drained from the bottom valve connection.
Air headers and distribution manifolds :
Air headers and distribution manifolds provide customers with many configurations for isolation manifolds.
Syphons :
Syphons are used to protect pressure gauges against pulsation of the medium and overheating. A syphon is installed at the thread connection of the pressure gauge or at the upstream fitted stop valve. A condensate is formed in the bend of the syphon, which prevents the hot medium from reaching the pressure measuring instrument. Syphons isolate pressure instruments from high temperatures.
Vent Protector :
The Vent Protector Fitting is used to protect tubes that are exposed to atmospheric pressure, instruments that are open to atmospheric pressure and every tube outlet that is open to atmospheric pressure.
